USB 560 FM

The Z Audio USB 560 FM P.A. Mixer Amplifier is designed for professional public-address applications requiring compact construction and convenient audio control. Delivering 60W RMS output power and 80W maximum power, it features a sturdy black cabinet, front-panel microphone controls, monitoring indicators and an integrated multimedia player for easy operation.

Equipped with 3 microphone channels and 1 AUX input, the USB 560 FM supports multiple compatible audio sources. Its built-in multimedia player offers Bluetooth, USB, MMC and SD connectivity, along with MP3 playback and recording functionality. The integrated FM receiver supports an 88–108MHz tuning range, while the included remote control provides convenient access to supported multimedia functions.

The Z Audio USB 560 FM also features adjustable bass and treble controls and an echo/reverb system for microphone applications. Supporting 4Ω, 8Ω, 16Ω and 100V speaker outputs, along with AC and 12V DC power options, it is suitable for compatible offices, schools, shops, meeting rooms and public announcement systems.

Key Features

• 60W RMS Output Power

• 80W Maximum Output Power

• Professional PA Mixer Amplifier

• 3 Microphone Input Channels

• 1 AUX Input Channel

• Bluetooth Connectivity

• MP3 Player with Recording

• USB/MMC/SD Playback

• Remote Control Included

• Built-in FM Receiver

• Adjustable Bass and Treble

• Echo and Reverb System

• 4Ω, 8Ω and 16Ω Speaker Outputs

• 100V Speaker Output

• AC and 12V DC Power Supply Options

• Compact Black Cabinet

Technical Specifications

• Product Name: USB 560 FM

• Category: P.A. Mixer Amplifiers

• Brand: Z Audio

• Power Output: 60W RMS at 10% THD / 80W Max

• Microphone Inputs: 3 Mic, 0.65mV / 4.7kΩ

• AUX Inputs: 1 AUX, 100mV / 470kΩ

• Frequency Response: 50Hz–15kHz ±3dB

• Bass Control: ±10dB at 100Hz

• Treble Control: ±10dB at 10kHz

• Speaker Output: 4Ω, 8Ω, 16Ω & 100V

• Line Output: 1V / 1kΩ

• AC Power Supply: 220–240V, 50/60Hz

• DC Power Supply: 12V (12V Car Battery)

• Multimedia Player: MP3 Player / Recorder

• Connectivity: Bluetooth, USB, MMC, SD

• Remote Control: Included

• FM Receiver: 88–108MHz

• Echo/Reverb: 60–300ms, 300–500ms, 500–650ms

• Dimensions: 380 × 363 × 145 mm

• Weight: 5,600g (Catalogue)

• Colour: Black
